measuring range: up to11’500m
display: m or ft, 5 digits, digital
scale: 1 m or 1 ft
QNH: indication of air pressure in hPa or in inHg

3 Altimeters:

·        ALT1 – absolute altimeter

·        ALT2 – absolute- or relativealtimeter

·        ALT3 – differential altimeter

Digital technology withadjustable Smart-filter (turbulence filter)

AnalogVariometer
display: ±10 m/s or ± 20 ft/min x100
scale: 0,2 m/s or 0,4 ft/min x100
Patented display mode with stable scale over the entire display range

DigitalVariometer
measuring range: ±96 m/s
display: m/s or ft/min x 100
scale: 0,1 m/s or 0,1 ft/min x100

·        6 audio volume settings

·        climb acoustic is tone- and intervalmodulated

·        adjustable response threshold

·        ASI (acoustic scaleindicator) – may be switched-on/off

·        adjustable integrator: from 1sec. up to 30 sec.

real time clock (12/24 hours)with date and automatic calendar
stop watch: up to 99 h 59 min. 59 sec.
Flight timer: automatic start function

measuring range: - 20 °C upto +76 °C
display mode: °C or °F
scale: 0,1 °C or 0,1 °F, may be calibrated

records max. 40 flights

·        dimensions: 138 x 74 x 23 mm

·        weight: 182 g (incl. 2batteries)

·        power supply: 2 Alkalinebatteries, NiMh-accumulators, continuous monitoring of battery voltage, autopower-off when not in use.

·        operating time: more than 250hours

·        operating temperature: -10 °Cup to +60 °C

·        storage temperature: -30°Cbis 70°C

·        warranty: 24 months

·        scope of supply: incl.paraglider clamp, batteries and carry bag
