OZONE JOMO

¥19000 原价:¥0
ENA类伞头

详情描述

JOMO

The Jomo is a lightweight high performance beginner intermediate wingdesigned for a wide range of hike & fly pilots. First and foremost it is asafe, fun, and easy high-performance wing ideal for the newly qualified,intermediate XC pilots and experienced alike. Reliable and dependable, it isperfect for pilots who require a safe and solid lightweight wing for ridgesoaring, thermalling, XC flying and beyond.

Certified EN A and based on the Mojo 5, the Jomo significantly reducesboth weight and packing volume.

These advantages give the Jomo the edge on the ground making it easier,lighter and smaller to carry with improved launching characteristics and easierinflation and ground handling than its heavier cousin. Launching the JOMO inthe mountains is less stressful, easier, and safer, thanks to its lightweightdesign. Setting up is easy; the risers are simple and uncluttered. The winginflates smoothly - without overshooting or hanging back - even in zero windconditions. In stronger winds it inflates progressively with less tendency to“shoot up” and pull the pilot off their feet.

In the air, the lower weight reduces the inertia making the wing morepitch stable and lighter to control. With an optimised number of cells andprofile, the Jomo is aerodynamically very clean. The reduced sail drag,optimised line layout, reduction in overall line length, and newly-shaped cellopenings push performance to the top of the category without compromisingsafety.

SIZES


XS

S

M

L

XL

Number of cells

40

40

40

40

40

PProjected area (m2)

18.7

20.3

22.1

24

26.1

Flat area (m2)

22

23.9

26

28.3

30.7

Projected span (m)

8.05

8.39

8.75

9.12

9.51

Flat span (m)

10.39

10.83

11.29

11.77

12.27

Projected Aspect   Ratio

3.46

3.46

3.46

3.46

3.46

Flat aspect ratio

4.9

4.9

4.9

4.9

4.9

Root Chord (m)

2.72

2.83

2.95

3.08

3.21

Glider Weight



3.77

3.98


In-flight weight range (kg)

55-70

65-85

80-100

95-115

110-130

EN*

A

A

A

A

A

*Certified by FFVL Aerotest so can be legally flown in Germany

MATERIALS

·        Top Surface Cloth: Dominico N20D / Skytex27 Classic

·        Bottom Surface Cloth: Skytex 27 Classic

·        Rib cloth: Skytex 40 Hard / Skytex 27 Hard

·        Upper lines: Liros DSL serie

·        Mid lines: Liros DSL serie

·        Lower Lines: Edelrid 6843 serie

DOWNLOADS

·        Line Chart

·        Rigging Diagram
